Flexible Bending Center with High Precision CNC System
Advanced automated bending center featuring precision CNC control and motion control cards for enhanced manufacturing efficiency and accuracy.
Product Description
The D.K. Histron HC-2000 pressure arm flexible bending center with 2000mm bending length is suitable for large sheet processing. The self-developed control system with complete source code can easily open API interfaces for deep integration with customer MES/ERP systems, becoming a natural component of smart factories. The system adopts EtherCAT bus protocol, providing high-speed communication and enhanced diagnostic capabilities for complex bending applications.
Model Features
- Pressure arm feeding system for high versatility
- Customizable auxiliary folding knife and power hinge knife
- Customized processing of workpiece bending height
- Customized presser foot lifting function
- High-speed motors for improved processing efficiency
Technical Parameters
| Model |
HC-2000 |
HC-2000P |
| Feeding structure |
Pressure arm type |
Pressure arm type |
| Minimum internal dimensions for quadrilateral forming |
180mm x 280mm |
180mm x 280mm |
| Bending height |
170mm (customizable) |
170mm (customizable) |
| Average power |
About 2.3KW |
About 2.6KW |
| User operating environment |
Operation system above Win7 |
Operation system above Win7 |
| Maximum bending thickness |
Cold plate 1.5mm
304 stainless steel 1.0mm |
Cold plate 2.0mm
304 stainless steel 1.5mm |
| Number of axles |
13 |
13 |
Applications
Control System
The bending center control system employs a top-level computer numerical control (CNC) system integrated with motion control cards. The CNC system features an intuitive human-machine interface and supports graphical programming. With exceptional position calculation capabilities, it significantly enhances production efficiency and precision in automated manufacturing. The motion control cards support 24-axis operation, with an expandable capacity up to 64 axes, and utilize EtherCAT bus control for high-precision motion control.
Operation Interface
The interface is simple, easy to learn, with good human-computer interaction.
FAQ:
Can you arrange samples for me?
Of course, we provide free samples by customer's requirements.
What is the warranty period for the machine?
The warranty period for the machine is one year. Lifetime maintenance and upgrade services are provided after the warranty period.
What is the MOQ of the machine?
The MOQ is 1 set.
Are all the machines standard?
No, customization is available. We can manufacture non-standard machines by customer's requirements.
What products can your machines produce?
Applications include: File cabinetry, Aluminum veneer wall industry, Stainless steel kitchenware industry, Refrigeration equipment industry, Chassis and Cabinet industry, Laboratory construction industry, Metal door industry and more.
What types of sheet materials can your machine bend?
Typically, carbon sheet, aluminum sheet, stainless sheet and galvanized sheet are available.
